Full Color Led Video Display Outdoor Glass Advertising Display
Product Features
1. High transparency rate, 80% transparency rate without affecting
day lighting. No need other heat dissipation system.
2. PCB board is only 10mm thickness, light weight, and does not
occupy space, without changing the appearance and structure of the
building.
3. Fast lock systems ensure fast installation and saving time and
labor cost.
4. The light weight of 5kg/panel LED screen is easy to carry,
transport and install - saving good amount of money on your labor
costs.
5. The Transparent LED Screen for Shopping Mall is known for its
silence operation and low power consumption. It is also known for
fast heat dissipation which will save more energy.
6. Cut on the electricity expenses and help environment with this
highly advanced advertising display.
FREQUENCY ASKED QUESTIONS
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display
industry. We can offer better price than trading Company.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has
difference requirements, and we quote according to your detailed
requirements.
Q: Can I use my own forwarder to transport the products for me?
A: Yes, if you have your own forwarder, you can let your forwarder
ship the products for you. But it is suggested that use our
forwarder because we have long-term good relationship with them for
good price and service.
Q: What is the payment method?
A: We support a variety of payment methods, such as T/T, western
union, paypal, moneygram.
Q: What's the payment terms?
A: 70% deposit to start production, and 30% balance to be clear
before delivery.
Q: Where the led display is used for?
A: Indoor & outdoor use. Widely used for backdrop of staging event,
rental business, liveshow, concert, etc.
Product Parmeters
| Item | Value |
| Model | CDG-391 | CDG-781 | CDG-151 | CDG-101 | CDG-390 | CDG-780 | CDG-710 | CDG-101 | CDG-101 |
| Pixel pitch | 3.91-7.81 | 7.81-7.81 | 7.81-15.62 | 10.4-10.4 | 3.91-7.81 | 7.81-7.81 | 7.81-15.62 | 10.4-10.4 | 15.64-15.64 |
| Pixel Density (dots/㎡) | 32768 | 16384 | 8192 | 9216 | 32768 | 16384 | 8192 | 9216 | 4096 |
| Power Consumption ( W/㎡ Average/Max.) | 120/400 | 260/950 | 250/920 | 220/900 | 220/900 | 200/860 |
| Usage | Indoor | Semi-outdoor |
| Brightness (CD/m2) | > 1000 | > 4000 |
| Pixel Configuration | 1R1G1B |
| LED Encapsulation | SMD 3in1 |
| Cabinet Size(mm) | 500 * 1000 |
| Cabinet material | Aluminum |
| Weight | ≈15KG/SQM |
| Transparence | > 80% |
| Viewing Angle | H: 120° V: 120° |
| Refresh Rate | > 1920HZ |
| Frame Frequency | 50 - 60Hz |
| Working Voltage | 110V / 220V AC±10% |
| MTBF | > 10,000 hrs |
| Lifespan | ≥ 100,000 hrs |
| Working Temperature / Humidity | -20℃ - +45℃ 10-90％ RH |
| Storage Temperature / Humidity | -25℃～50℃ 10～90%RH |
Why choose us
1. Diversified products: Varieties of models for outdoor/indoor LED
display screens, and customized cabinets available, meet all
requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product
design and production. As the quantity of PCB and other components
have been decreased and simplified. Our engineers can concern in a
small quantity of defect to solve and it will be a substantial
boost of the yield rate. 100% testing before packing make sure our
quality before delivery.
3. Best raw materials: High quality, good stability and
reliability.
4. Competitive price: Factory price which is competitive in the
market.
5. Prompt &Professional service: Any inquires will be replied
within 12 hours in working days and you’ll get helpful suggestions
from us.
The products we offer
Indoor fixed and rental:
P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81
P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led
display.creative led display (ball led display, dj led display) and
other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any
clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
