P3.91 P4.81 P5.95 P6.25 500 X 500mm Front Service Rental Outdoor
Led Screen
Product Features
1. High bright 3in1 LED SMD lamps with best plastic package suite
are not easy to be damaged and ensures the best viewing angle.
2. Fast installation and front maintenance design is available,
make your LED display business more proffessional and easier.
3. Modular design, any cabinet could removed and replace when it is
not working well.
4. Fine pixel pitch rental solution is available.
5. Detachable panel: Independent design of module, frame and
control box.
6. Protective covers reduce all potential damages to a maximum
extent.
FREQUENCY ASKED QUESTIONS
Q: How to get the price list?
A: Sorry that we don't have price list because each project has
difference requirements, and we quote according to your detailed
requirements.
Q: Can I use my own forwarder to transport the products for me?
A: Yes, if you have your own forwarder, you can let your forwarder
ship the products for you. But it is suggested that use our
forwarder because we have long-term good relationship with them for
good price and service.
Q: How can I get the sample to check your quality?
A: After price confirmation, you can require for samples to check
our product’s quality.
Q: Why is brightness important?
A: If you want images to be seen during the day, your display must
compete with the Sun. The Sun emits approximately 4,000 nits of
light (a nit is a measurement of light emitted from a device.) In
order for an LED display to display effectively during the day, a
minimum of 5,000 nits is required.
Q: What is the life expectancy of LED display?
A: LEDs have an average life span of 100,000 hours or 10+ years.
Your LED display must be of quality materials and sealed from the
harsh elements of outdoors to extend the lifetime.
Q: What is the brightness control, how to achieve?
A: Brightness control is needed since the environment brightness
level is changing during the daytime. If you don’t adjust the
brightness according to the environment, the LED display screen
system will not have a perfect viewing effect. There’s two ways to
achieve the brightness control: manually changing & automatic
changing. The automatic brightness changing can adjust the LED
display screen system’s brightness perfectly according to the
environment brightness level.
Product Parmeters
| Item | Value |
| Pixel pitch | 3.91 | 4.81 | 5.95 |
| Usage | Indoor |
| Pixel Configuration | 1R1G1B |
| LED Encapsulation | SMD2121 | SMD1921 | SMD2727 |
| Pixel Density (dots/㎡) | 65410 | 43222 | 28246 |
| Brightness (CD/m2) | 800~1200 | 3000~3500 | 3500~4000 | 4000~4500 |
| Module Size(mm) | 250*250 |
| Cabinet Size(mm) | 500*500 |
| Cabinet material | Polymer nanocomposites |
| Weight | ≈30KG/SQM |
| Viewing Angle | H: 120° V: 120° |
| Refresh Rate | 1920~3840HZ |
| Frame Frequency | 50 - 60Hz |
| Working Voltage | 110V / 220V AC±10% |
| MTBF | > 10,000 hrs |
| Lifespan | ≥ 100,000 hrs |
| Power Consumption (Avg./Max. W/㎡) | 180/460 | 350/960 | 230/560 | 340/930 |
| Working Temperature / Humidity | -20℃ - +45℃ 10-90％ RH |
| Storage Temperature / Humidity | -25℃～50℃ 10～90%RH |
Why choose us
1. Diversified products: Varieties of models for outdoor/indoor LED
display screens, and customized cabinets available, meet all
requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product
design and production. As the quantity of PCB and other components
have been decreased and simplified. Our engineers can concern in a
small quantity of defect to solve and it will be a substantial
boost of the yield rate. 100% testing before packing make sure our
quality before delivery.
3. Best raw materials: High quality, good stability and
reliability.
4. Competitive price: Factory price which is competitive in the
market.
5. Prompt &Professional service: Any inquires will be replied
within 12 hours in working days and you’ll get helpful suggestions
from us.
The products we offer
Indoor fixed and rental:
P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81
P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led
display.creative led display (ball led display, dj led display) and
other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any
clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
