High Quality Hd Video Small Pixel Pitch Indoor P2.5 Led Display
Product features:
1. High refresh rate and high gray scale to make the picture vivid
which meets the demand of high visual quality of commercial usage.
2. Neat appearance,light weight,small size and safe 5V low voltage
power supply system all make the module more attractive.
3. Fast installation and front maintenance design is available,
make your LED display business more proffessional and easier.
4. Free training after order, and offer you the training course in
detail.
5. We use aerial grade brands connectors to ensure the stable
transmission of power and signal.
6. Four or even six layer design PCB is adopted to ensure the
stability.
RFQ:
Q: Do you have CE/ROHS certificate?
A: Yes, we have the certificate.
Q: What's the shiping method?
A: Our products could be shipped by sea, by air, and by express.
Q: Can I use my own forwarder to transport the products for me?
A: Yes, if you have your own forwarder, you can let your forwarder
ship the products for you. But it is suggested that use our
forwarder because we have long-term good relationship with them for
good price and service.
Q: Where the led display is used for?
A: Indoor & outdoor use. Widely used for backdrop of staging event,
rental business, liveshow, concert, etc.
Q: What is the delivery guarantee?
A: Guarantee time: 2 years. Within 2 years, if any part failed, we
send new parts or repair for free, You will undertake shipping cost
from your city to China and we undertake shipping cost from China
to your city. After 2 years, we only charge cost price for parts
and repairements, and you need to pay shipping cost go and back.
Q: What's the control system?
A: Control system could be Linsn, Nova-star, Xixun, Color
light...Usually client use Linsn for fixed installation led
screens, and Nova-star system for rental screens.
Product specification:
| INDOOR SMALL PIXEL PITCH |
| Item | Value |
| Model No. | CDN-151 | CDN-161 | CDN-181 | CDN-191 | CDN-201 | CDN-251 | CDN-301 |
| Pixel Pitch(mm) | 1.5625 | 1.667 | 1.875 | 1.923 | 2 | 2.5 | 3 |
| Pixel Density(dots/sqm) | 409600 | 359856 | 284444 | 270422 | 250000 | 160000 | 111111 |
| LED Type | SMD1010 | SMD2121 |
| Viewing Angle(Deg.) | H:120 V:120 |
| Brightness(nits) | 800~1000 | 800~1200 |
| Refresh Rate(Hz) | 360~1920 |
| Module Size(mm) | 200*100 | 120*120 | 200*100 | 128*128 | 160*160 | 192*192 |
| Cabinet Size Recommended (mm) | 400*300 | 480*480 | 400*300 | 512*512 | 480*480 | 576*576 |
| Cabinet Material | Die-casting aluminum / Magnalium | Steel with powder painted |
| Cabinet Weight | ≤35KG/SQM | ≈45KG/SQM |
| Power Consumption (Avg./Max. W/㎡) | 500/1250 | 600/1500 | 500/1250 | 320/800 | 310/780 | 270/680 |
| IP Grade | IP43 / IP31 |
| Operating Temp/Humidity (℃/%RH) | -20℃～45℃10～90%RH |
| Storage Temp/Humidity (℃/%RH) | -25℃～50℃ 10～90%RH |
| Lifetime(hours) | ≥50000(Normal Temp) |
Why choose us?
1. Diversified products: Varieties of models for outdoor/indoor LED
display screens, and customized cabinets available, meet all
requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product
design and production. As the quantity of PCB and other components
have been decreased and simplified. Our engineers can concern in a
small quantity of defect to solve and it will be a substantial
boost of the yield rate. 100% testing before packing make sure our
quality before delivery.
3. Best raw materials: High quality, good stability and
reliability.
4. Competitive price: Factory price which is competitive in the
market.
5. Prompt &Professional service: Any inquires will be replied
within 12 hours in working days and you’ll get helpful suggestions
from us.
The products we offer:
Indoor fixed and rental:
P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81
P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led
display.creative led display (ball led display, dj led display) and
other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any
clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
