P1.2 Indoor Hanging Wall Installation Small Spacing Led Display
Product features:
1. Dual back-up: both power supply and system dual back-up are
optional, reliable performance.
2. Modular design, any cabinet could removed and replace when it is
not working well.
3. Special heat-disspating channel design to ensure heat radiate
rapidly and effectively.
4. Support all types of video, graphics, animation, message, etc,
support PC online or offline control, also can remote control with
asynchronous system, or Wifi control, 3G control.
5. IP68 waterproof, meeting the demands of outdoor applications.
6. Input Voltage:AC100-220V.
RFQ:
Q: Outdoor screen can't use surface mount LED?
A: We have outdoor SMD display now. We solve the problem of the
brightness and water proof. We use SMD3535 led chip, filling the
glue on the surface with IP65 cabinet.
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display
industry. We can offer better price than trading Company.
Q: When is the delivery time?
A: we will accomplish manufacturing within 10-30 days after
receiving deposit. If you need urgent, please kindly let us know,
in guaranteed of quality, we will try our best to produce faster.
Q: How can I get the sample to check your quality?
A: After price confirmation, you can require for samples to check
our product’s quality.
Q: When can I get the price?
A: We usually quote within 12 hours after we get your inquiry. If
you are very urgent to get the price, please tell us in your email
so that we will regard you inquiry priority.
Q: What is your term of delivery?
A: We accept EXW, FOB Shenzhen or door to door. You can choose the
one which is the most convenient or cost effective for you.
Product specification:
| INDOOR SMALL PIXEL PITCH |
| Item | Value |
| Model No. | CDN-151 | CDN-161 | CDN-181 | CDN-191 | CDN-201 | CDN-251 | CDN-301 |
| Pixel Pitch(mm) | 1.5625 | 1.667 | 1.875 | 1.923 | 2 | 2.5 | 3 |
| Pixel Density(dots/sqm) | 409600 | 359856 | 284444 | 270422 | 250000 | 160000 | 111111 |
| LED Type | SMD1010 | SMD2121 |
| Viewing Angle(Deg.) | H:120 V:120 |
| Brightness(nits) | 800~1000 | 800~1200 |
| Refresh Rate(Hz) | 360~1920 |
| Module Size(mm) | 200*100 | 120*120 | 200*100 | 128*128 | 160*160 | 192*192 |
| Cabinet Size Recommended (mm) | 400*300 | 480*480 | 400*300 | 512*512 | 480*480 | 576*576 |
| Cabinet Material | Die-casting aluminum / Magnalium | Steel with powder painted |
| Cabinet Weight | ≤35KG/SQM | ≈45KG/SQM |
| Power Consumption (Avg./Max. W/㎡) | 500/1250 | 600/1500 | 500/1250 | 320/800 | 310/780 | 270/680 |
| IP Grade | IP43 / IP31 |
| Operating Temp/Humidity (℃/%RH) | -20℃～45℃10～90%RH |
| Storage Temp/Humidity (℃/%RH) | -25℃～50℃ 10～90%RH |
| Lifetime(hours) | ≥50000(Normal Temp) |
The products we offer:
Indoor fixed and rental:
P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81
P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led
display.creative led display (ball led display, dj led display) and
other customerized led display products
Our advantages:
1. Goods is examined before delivery, professional QC team.
2. Variety of customized products to satisfy different
requestments.
3. Highest cost-effective price in the market.
4. All inquiry will be answered within 24 hours by a well-trained
and experienced staffs.
5. Top quality & reasonable price & responsible after service.
6. All private information will be well protected.
7. All products undergo a strict aging test. The 72 hours aging
test is conducted without die lamp, dim lamp, color difference and
mosaic. The product is deliveryed only if it passes the aging test
to ensure the best quality.
8. We specialize in high quality products.
9. We have professional R&D team who has professional
development ability.
10. We are factory, we can offer better price than trading Company.
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any
clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
