Fine Pixel Pitch Full Color P1.9 Indoor Led Video Wall Screen
Smd1010 High
Product features:
1. Neat appearance,light weight,small size and safe 5V low voltage
power supply system all make the module more attractive.
2. Special walldrape design, no need buy more structure for
installation.
3. Fast installation and front maintenance design is available,
make your LED display business more proffessional and easier.
4. Support all types of video, graphics, animation, message, etc,
support PC online or offline control, also can remote control with
asynchronous system, or Wifi control, 3G control.
5. Super flatness & uniformity, large viewing angle, high
brightness.
6. Long visual distance, screen can be viewed in a far away space.
RFQ:
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display
industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial
Zone, Shenzhen, China. We can pick you up from airport or your
hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has
difference requirements, and we quote according to your detailed
requirements.
Q: What's the shiping method?
A: Our products could be shipped by sea, by air, and by express.
Q: What's the Payment method?
A: T/T for bank transfer, 70% deposit before production, the
balance before delivery. But paypal, west union,etc. also
available.
Q: How can I get the sample to check your quality?
A: After price confirmation, you can require for samples to check
our product’s quality.
Product specification:
| INDOOR FIXED |
| Item | Value |
| Model No. | CDN-151 | CDN-161 | CDN-181 | CDN-191 | CDN-201 | CDN-251 | CDN-301 |
| Pixel Pitch(mm) | 1.5625 | 1.667 | 1.875 | 1.923 | 2 | 2.5 | 3 |
| Pixel Density(dots/sqm) | 409600 | 359856 | 284444 | 270422 | 250000 | 160000 | 111111 |
| LED Type | SMD1010 | SMD2121 |
| Viewing Angle(Deg.) | H:120 V:120 |
| Brightness(nits) | 800~1000 | 800~1200 |
| Refresh Rate(Hz) | 360~1920 |
| Module Size(mm) | 200*100 | 120*120 | 200*100 | 128*128 | 160*160 | 192*192 |
| Cabinet Size Recommended (mm) | 400*300 | 480*480 | 400*300 | 512*512 | 480*480 | 576*576 |
| Cabinet Material | Die-casting aluminum / Magnalium | Steel with powder painted |
| Cabinet Weight | ≤35KG/SQM | ≈45KG/SQM |
| Power Consumption (Avg./Max. W/㎡) | 500/1250 | 600/1500 | 500/1250 | 320/800 | 310/780 | 270/680 |
| IP Grade | IP43 / IP31 |
| Operating Temp/Humidity (℃/%RH) | -20℃～45℃10～90%RH |
| Storage Temp/Humidity (℃/%RH) | -25℃～50℃ 10～90%RH |
| Lifetime(hours) | ≥50000(Normal Temp) |
Why choose us?
1. Diversified products: Varieties of models for outdoor/indoor LED
display screens, and customized cabinets available, meet all
requirements and win more profits for customers.
2. Quality assurance: Quality control is taken both in product
design and production. As the quantity of PCB and other components
have been decreased and simplified. Our engineers can concern in a
small quantity of defect to solve and it will be a substantial
boost of the yield rate. 100% testing before packing make sure our
quality before delivery.
3. Best raw materials: High quality, good stability and
reliability.
4. Competitive price: Factory price which is competitive in the
market.
5. Prompt &Professional service: Any inquires will be replied
within 12 hours in working days and you’ll get helpful suggestions
from us.
The products we offer:
Indoor fixed and rental:
P1.667,P1.923,P2,P2.5,P3,P4,P5,P6,P3.91,P,4.81 P6.25,P7.62,P10
Outdoor fixed and rental: P3,P4,P5,P6,P3.91,P,4.81
P6.25,P8,P10,P12,P16,P20
Mobile truck led display, transparent glass window led
display.creative led display (ball led display, dj led display) and
other customerized led display products
Our Services
Pre-producing:
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing:
1. Producing progress updating for clients.
2. Provide Installation drawing for clients.
After service:
1. 2 years free maintenance.
2. 7 days a week, 24 hours a day on-line technical support for any
clients.
3. Free training for customers in factory.
4. Local Installation Guidance Service.
