Front Service Double Sided P16MM Outdoor Led Open Sign Display
Product Feature
1. Lightweight, adopt aluminum cabinet and light design, less
labors & easy in installation.
2. Soft rubber face cover, soft protection bar on the top of each
cabinets, safe for athletes.
3. Internal cabling connection. Less cables, it looks more clean
and also safe for athletes and audience. The signal and power
connection will not influenced by external break.
4. High transparency rate, 80% transparency rate without affecting
day lighting. No need other heat dissipation system.
5. PCB board is only 10mm thickness, light weight, and does not
occupy space, without changing the appearance and structure of the
building.
6. Fast lock systems ensure fast installation and saving time and
labor cost.
FREQUENCY ASKED QUESTIONS
Q:Are you a factory or trading company?
A:We are a factory with 10+ years experience in led display
industry. We can offer better price than trading Company.
Q: Where is your factory located? How can I visit there?
A: Our factory address is: B block, NO.56 Heng dong ling Industrial
Zone, Shenzhen, China. We can pick you up from airport or your
hotel for visiting.
Q: How to get the price list?
A: Sorry that we don't have price list because each project has
difference requirements, and we quote according to your detailed
requirements.
Q: Do you have any MOQ limit for led light order?
A: NO MOQ, 1pc for sample checking is available.
Q: How to proceed an order for led Dispaly?
A: Firstly let us know your requirements or application. Secondly
we quote according to your requirements or our suggestions. Thirdly
customer confirms the samples and places deposit for formal order.
Fourthly we arrange the production.
Q: Is it OK to print my logo on cabinet?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Famous Brands Raw Material Selection
1)LED: well-known international brand,with wide viewing angle
,little attenuation ,good heat dissipation, and vivid colors.
2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba,
avoidable the defective
phenomena, such as dark bright, virtual light and so on.
3) Power supply: industrial-strength brand.The power maximum power
resere of 20% the space , the range of voltage fluctuation is less
5%, high stability.
4) Connector: Aerial grade brands ensure the stable transmission of
power and signal.
5) PCB Board: adopt 4-layer design.
6) Easy installation:100 pieces of cabinets' installation can be
finished in one hour by one person.
The replacement of any cabinet can be done within 50 seconds.
| Item | Value |
| Model NO. | CDR-100D |
| Pixel Pitch | 10 |
| Pixel Density (dots/sqm) | 10000 |
| LED Type | DIP |
| Viewing Angle | H:120 V:60 |
| Brightness (nits) | 7000～10000 |
| Refresh Rate | 960 |
| Module Size(mm) | 160*160 |
| Cabinet Size | 960*960 |
| Cabinet Material | Steel with powder painted |
| Cabinet Weight | ≈ 45KG/SQM |
| Power Consumption (Avg./Max. W/㎡) | 400/980 |
| IP Grade | IP65/54 |
| Operating Temp/Humidity | -20℃～45℃ 10～90%RH |
| Storage Temp/Humidity | -25℃～50℃ 10～90%RH |
| Lifetime(hours) | ≥50000(Nomal Temp) |
